MIL-DTL-11603G(AT)
TABLE VI. Reverse range stall performance.
Item
Type I
Type II, III and IV
Input torque (lb-ft) (N-m)
648 to 652
748 to 752
(878 to 883)
1013 to 1018)
Input speed (rpm)
1855 max.
1410 max.
Oil pressure (psi (kPa)
Main
173 min.
173 min.
(1193 min.)
(1193 min.)
3.3.7 Neutral steer. When tested as specified in 4.5.10 the right and left steer clutch
pressure must increase gradually as the steer control is shift is moved, and at full right and left
steer the transmission performance shall be in accordance with table VII.
TABLE VII. Full steer performance.
Item
Full L.H. steer 1/
Full R.H. steer 1/
Oil pressure (psi) (kPa)
R.H. steer clutch
-
178 min. (1227 min.)
L.H. steer clutch
178 min. (1227 min.)
-
Lube
7 min. (48 min.)
7 min. (48 min)
1/ L.H. and R.H. are defined in 6.3.
3.3.8 Service brake capacity. When tested as specified in 4.5.11. The right and left hand
brakes shall hold the right and left hand outputs without movement.
3.3.9 Leakage. During and after an operational simulation, the transmission shall show
no evidence of a leak or drip (see "c" and "d" of 6.4).
3.3.10 Durability. The transmission shall require no repair and no maintenance other than
filter changes, oil changes, brake adjustments and low range and reverse band adjustments during
vehicle operation at a proving ground for distances up to 5000 miles (8047 kilometers (km).
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are
classified as follows:
a. First article inspection (see 4.2).
1. Preproduction inspection (see 4.2.1)
2. Initial production inspection (see 4.2.2)
b. Conformance inspections (CI) (see 4.3)
1. Examination (see 4.3.1)
2. Tests (see 4.3.2)
6
