MIL-DTL-11603G(AT)
1705
1855
3300
(4474)
3200
(4338)
3132
(4246)
3100
(4203)
3000
(4067)
2959
REJECTED
(4011)
2900
(3931)
1900
1700
1800
1600
TRANSMISSION INPUT SPEED (RPM) AT 650 LB-FT (881 N-M) INPUT TORQUE
NOTES:
1. Converter out oil temperature 200 to 225°F (93 to 107°C).
2. All figures shown in parenthesis are measured values expressed in metric terms.
FIGURE 1. CD 850-5 transmission acceptance limits high gear stall.
15
