MIL-DTL-11603G(AT)
TABLE III. High range no-load performance.
Item
Type I
Type II and III
Type IV
Input torque (lb-ft) (N-m)
135 max. (183) 180 max. (244)
180 max. (244)
Output speed (rpm)
1360 min.
1585 min.
1585 min.
Oil pressure (psi) (kPa)
Main
113 - 169
113 - 169
122 - 146
(779 - 1165)
(779 - 1165)
(779 - 1165)
Converter "in"
70 min.
80 min.
95 min.
Lube
40 - 70
42 - 71
49 - 71
Oil flows (gal/min)
Main
47 min.
45 min.
52 - 61 min.
Converter "out"
37 min.
31 min.
36 min.
3.3.4 Low range stall. When tested as specified in 4.5.8.1, the transmission low range
stall performance shall be in accordance with table IV.
TABLE IV. Low range stall performance.
Item
Type I
Type II, III and IV
Input torque (lb-ft) (N-m)
648 to 652 (878 - 883)
748 to 752 (1014 - 1019)
Input speed (rpm)
1855 max.
1410 max.
3.3.5 Low range no-load. When tested as specified in 4.5.8.2 the transmission low range
no load performance shall be in accordance with table V.
TABLE V. Low range no-load performance.
Item
Type I
Type II and III
Type IV
Input torque (lb-ft) (N-m)
152 max.
161 max.
145 max.
Output speed (rpm)
492 min.
573 min.
573 min.
Oil pressure (psi) (kPa)
Main
184
179 min.
200 min.
(1268 min.)
(1234 min.)
(1379 min.)
Converter "in"
63-95
65-95
75-100
Lube
26 min.
26 min.
40 min.
3.3.6 Reverse range stall. When tested as specified in 4.5.9 the transmission reverse
range stall performance shall be in accordance with table VI.
5
