MIL-DTL-62030E(AT)
3.4.12 Low speed oil pressure and temperature. With an input speed of 600-650 rpm, no
load on the output, and the "pivot" valve in the "land" position, main oil pressure and cooler "in"
oil temperature shall be as specified in table VII (see 4.5.5.12).
TABLE VII. Low speed oil pressure and temperature.
Range
Main oil pressure
Cooler "in" oil temp
88 - 107°C (190 - 225°F)
4th range
648 kPa (94 psi) min
896 kPa (130 psi) min 77 - 107°C (170 - 225°F)
3rd range
979 kPa (142 psi) min 77 - 107°C (170 - 225°F)
2nd range
1172 kPa (170 psi) min 77 - 107°C (170 - 225°F)
1st range
Reverse 2 range 1034 kPa (150 psi) min 77 - 107°C (170 - 225°F)
Reverse 1 range 862 kPa (125 psi) min 77 - 107°C (170 - 225°F)
3.5 Interface requirements. The assembly shall conform to the interface envelope
dimensions, mounting and electrical interfaces in the applicable drawing (see 4.6).
3.6 Support and ownership requirements. The assembly shall possess the following life
cycle ownership characteristics (see 4.7).
3.6.1 Safety. The transmission shall pose no hazards, physically or electrically to
personnel (see 4.7.1).
3.6.2 Reliability. After proper installation in the vehicle for which the transmission has
been procured, the transmission shall require no repair and no maintenance other than filter
changes, oil changes, oil additions, and brake adjustments during vehicle operation at a
Government proving ground for distances up to 8000 kilometers (km) (5000 miles) (see 4.7.2).
3.6.3 Leakage. After dynamometer operation, transmission shall evidence no leakage
(see 4.5.3, 4.7.3, and 6.6.1).
3.6.4 Exterior surface treatment. All exposed surfaces of the transmission and its
components shall be cleaned, painted or treated for corrosion resistance as specified on applicable
drawings (see 4.5.3).
3.6.5 Nameplate. Unless otherwise specified on the applicable drawing, the nameplate,
data and instruction plates shall conform to the applicable provisions of A-A-50271 (see 4.5.3).
7
