MIL-PRF-46750E(AT)
4.2.1 Verification alternatives. The manufacturer may propose alternative test methods,
techniques, or equipment, including the application of statistical processes control, tool control, or
cost-effective sampling procedures, to verify performance. See the contract for alternatives that
replace verification required by this specification.
4.2.2 Inspection conditions. Unless otherwise specified (see 6.2), all inspections shall be
performed under the following controlled ambient conditions:
a. Temperature: 23 ± 10°C (73 ± 18°F)
b. Atmospheric pressure: 92 ± 11 kPa (28.5 (+2.0, - 4.5) inches of Hg)
c. Relative humidity: 50 + 30 percent (%).
4.3 Order of inspections. The inspection sequence may be in any order.
4.3.1 First article inspection. When specified (see 6.2 and 6.3), first article inspection shall
include all the verifications listed in table V.
Table V. Verification Methods.
Require-
Verifica-
Require-
Verifica-
Title
ments
tion
Title
ments
tion
Operating requirements
3.4
4.3.3
Upshift
3.4.12
4.3.3.14
Oil, In-vehicle operation
3.4.1
4.3.3.1
Speedometer drive
3.4.13
4.3.3.15
4.3.3.1.1
Oil warm-up
3.4.14
4.3.3.16
Functional operation
3.4.2
4.3.3.2
Range shifts
3.4.15
4.3.3.17
First-second range shift
3.4.2.1
4.3.3.2.1
Output, steer pressure
3.4.16
4.3.3.18
Brake adjustment
3.4.2.2
4.3.3.2.2
Brake and steer clutch
3.4.17
4.3.3.19
Fourth range stall
3.4.3
4.3.3.3
Valve movement
3.4.18
4.3.3.20
Third range steer
3.4.4
4.3.3.4
Leakage
3.4.19
4.3.3.21
Lockup clutch
3.4.5.1
4.3.3.5
Main assembly
3.4.20.1
4.3.3.22
engagement-no load
Input transfer assembly
3.4.20.2
4.3.3.23
Lockup clutch- load
3.4.5.2
4.3.3.6
Interface requirements
3.5
4.3.4
Lockup clutch
3.4.5.3
4.3.3.7
Interface dimensions
3.5.1
4.3.4
disengagement-
Ownership and support
3.6
4.3.5
no load
requirements
First range steer
3.4.6
4.3.3.8
Durability
3.6.1
4.3.5.1
Reverse range
3.4.7
4.3.3.9
Exterior surface
3.6.2
4.3.5.2
Service brake
3.4.8
4.3.3.10
Identification and
3.6.3
4.3.5.3
marking
Friction loss
3.4.9
4.3.3.11
Safety
3.6.4
4.3.5.4
Coolant pump flow
3.4.10
4.3.3.12
Operating environment
3.7
4.3.6
Shift inhibitor
3.4.11
4.3.3.13
8
